BY-300、400、600、800、1000、1250 ( Sugar ) Coating Machine

Release time:2019/06/12 Coating equipment Simple coating machine Views:63

specification

Main application:

These machines sugar coat the tablets and pills for pharmaceutical and food industries. It is also used for rolling and heating beans and edible nuts or seeds. The sugar coating round pot is elevated with an elevation of 30 degrees to the horizontal, and the heater such as gas heater or electrical heater can be placed directly under the pot. A separated blower with electrical heater is provided with the machine. The pipe of the blower stretches into the pot for heating or cooling purpose. The thermal capacity can be selected in two levels.

Characteristics:

Able to be matched with frequency controller

Able to be matched with dust-removal system

It can be made to totally-enclosed type, saved with airbrush system, and meets the requirements of GMP.

Technique parameter:

Model BY-300 BY-400 BY-600
Dia of the sugar coating pot (mm) 300 400 600
Speed of the sugar coating pot (r/min) 46 46 40
Motor power(kw) 0.37 0.55 0.55
Heating wire power (w) 500 500 800
Blower power (w) 40 40 60
Capacity (kg /cycle) 2 5 15
Weight (kg) 65 70 120
Overall dimensions (mm) 485×585×766 485×585×810 700×540×1300
Power of other heating (w) 500 500 600



Model BY-800 BY-1000 BY-1250
Dia of the sugar coating pot (mm) 800 1000 1250
Speed of the sugar coating pot (r/min) 32 32 30
Motor power(kw) 1.1 1.5 2.2
Heating wire power (w) 1000 1000 1000
Blower power (w) 250 250 250
Capacity (kg /cycle) 30~50 50~70 90~150
Weight (kg) 240 250 280
Overall dimensions (mm) 925×900×1500 1100×1100×1600 1200×1250×1630
Power of other heating (w) 1000×2 1000×2 1000×2
