TDP1.5、5、6 Single-Punch Tablet Press

Release time:2019/06/14 Single punching machine TDP single punch Views:68

本机用以将各种颗粒状原料压制成圆片,是适合于实验室试制和小规模生产。其特点是一种小型台式电动连续压片的机器,也可以手摇。机上只可装一付冲模,物料的充填深度,压片厚度均可调节。

specification

Main application:

This machine is used for pressing different kinds of granular raw materials into round tablets. It is applicable to trial manufacturing in lab or batch production in small amount different kinds of tablets, sugar pieces, calcium tablets and tablets of abnormal shape. It features a small desktop type press for motive and continual sheeting. It can also be hand-operated. Only one pair of punching die can be erected on this press. Both filling depth of material and thickness of tablet are adjustable.



Technique Parameter:

Model TDP-1.5 TDP-5 TDP-6
Max. Pressure (kn) 15 50 60
Max. dia. of tablet (mm) 12 16 25
Max. Depth of fill (mm) 12 16 16
Thickness of largest tablet (mm) 6 6 6
Production capacity (pcs/h) 6000 6000 6000
. Motor (kw) 0.55 0.75 1.1
Overall size(mm) 700*370*800 700*400*800 700*500*900
Net weight(kg) 90 125 140
