WFJ-15、20 Micro Crushing Unit

Release time:2019/06/28 Crusher series Superfine pulverizer Views:74

specification

Main Uses:

The machine made up of main engine, auxility engine and electric-box, featuring winnowing without sieve or mesh, ever granule size, continuous operation, etc. The machine reaches advanced world-level and is widely used for material grinding in pharmaceutical, chemical and foodstuff industries, etc.

Working Principle:

Materials are transported into smashing mesh via screw conveyor, then crushed by the high-speed revolving razor blade. With the negative pressure, materials will be transported into cyclone separator, ejected by pass-breezing machine. Without the powder float in whole producion line the powder float in the sky.

Technical parameters:

Model WFJ-15 WFJ-20 WFJ-30 WFJ-60 WFJ-80
Capacity(kg) 20~100 50~200 100~400 200~800 300~1000
Feed size

(mm)

<10 <10 <12 <12 <12
Output size (mesh) 80-320 (adjustable)
Motor power (kw) 13.37 18.37 42.5 77.5 96
Spindle speed (rpm) 5800 4200 3800 3200 2800
Weight (kg) 850 1000 1300 2500 3000
Overall size(L*W*H)(mm) 4200*1200*2700 4700*1250*2900 6640*1300*3960 7500*2300*4530

8500*2500*4600

main feature:

1: this crusher is made up of stainless steel(we also can do as consumer requirement)

2: this crusher meeting ISO9001 certificate

3: this crusher can crush the raw material into very fine powder

4: this crusher no sieve. match water cooling system

5: this crusher match pulse dust absorption system

6: the voltage: 220v or 380v or as consumer requirement

7: guarantee: 1 year
