GFG High-efficiency Fluid Bed Dryer

Release time:2019/07/12 Boiling dry Drying equipment Product Views:60

specification

Principle
When air is purified and heated, it is introduced from the bottom of exhaust fan and passes through screen plate of raw material. In working chamber, the state of fluidization is formed through stirring and negative pressure. The moisture is evaporated and removed rapidly and raw material is dried quickly

Features
1. The structure of fluid bed is of round so as to avoid dead corner.
Inside the hopper there is a stir in order to avoid agglomeration of raw material and forming canal of flow. (Small machine does not support stirrer)
2. The granule is discharged through the method of turning over. In this way, it is very convenient and quickly. Discharging system can be designed by requirement.
3. It is operated at the conditions of negative pressure and seal. The air is filtered. Therefore it is simple in operation and convenient in cleaning. It is ideal equipment that is in conformity with the requirement of GMP.
4. The drying speed is fast and temperature is uniform. In general the drying time is 20-30 minutes.



Technical Parameter

Model GFG
Feeding(kg) 60 100 120 150 200 300 500
Fan Air volume(m³/h) 2361 3488 3488 4901 6032 7800 10800
Air pressure(mm) 594 533 533 679 787 950 950
Power(kw) 7.5 11 11 15 22 30 45
Mixing power(kw) 0.55 0.55 0.55 0.55 0.75 0.75 1.1
Mixing rotation speed(r/min) 11
Steam consumption(kg/h) 141 170 170 240 282 366 451
Operating time(min) 15-30
Machine height Square(min) 2750 2850 2850 2900 3100 3300 3650
Round(min) 2700 2900 2900 2900 3100 3600 3850
